FOT3403 CWDM Optical Power Meter

FOT3403 series CWDM optical power meter is a CWDM optical network channel detector. It is mainly used to measure and monitor the power of up to 6 or 18 CWDM channels. The test power value can be displayed in columngraph or list mode, and the power value of a certain channel can also be viewed separately. The whole machine adopts 3.5-inch 320*480 high-definition color LCD, small size, light weight, strong and durable. It can replace the current high-cost spectrometer for testing CWDM, which can provide fast and reliable measurement in various environments. It is specially designed and developed for the installation, acceptance and maintenance of CWDM optical network, and has become a necessary special tool for CWDM access network maintenance and installation.

Product Features;

l Support 6 or 18 channels wavelength power test

l Easy to carry and easy to operate

l Display test data in column graph or list mode

l 3.5 inch TFT LCD. resolution 320*480

l Single channel power information can be viewed

l User define threshold and stored

l OPM/VFL /RJ45 sequence/ cable length/cable tracker

l Portable battery charging

Inquire Online

——

Specification

Model	FOT3403-6			FOT3403-18
CWDM Optical Power Meter
Detector type		InGaAs
Fiber Type		SMF 9/125μm
Connector		FC/UPC
Wave Range		1270-1370nm/1271-1371nm	1270-1610nm/1271-1611nm
Power Range		-70~+10dBm
Channels		6	18
Channel Spacing		20nm
Channel Band pass		±6.5nm
Power resolution		0.01dB
Power accuracy		±0.5dB
Return loss		>45dB
Isolation of adjacent channels		≥25dB
Unit		mW/μW/nW/dBm/dB(REF)
Data storage		1000
Optical Power Meter
Connector		FC/PC
Calibration Wavelength		850/98/1300/1310/1490/1550/1625/1650nm
Power Range		-70~+10dBm	-50~+26dBm
Unit		mW/μW/nW/dBm/dB(REF)
Test Accuracy		±0.25dB(5%)
Resolution		0.01dB
VFL
Wavelength		650nm±20nm
Output power		≥10mW
Mode		CW/1Hz/2Hz
Connector		Universal joint FC/SC/ST
RJ45 Cable Length
Test Distance		≤300m
RJ45 Cable Sequence
Test Distance		≤300m
RJ45 Cable Tracker
Test Distance		≤300m
Others
Display		3inch320*480 Color LCD screen
Data Interface		Micro USB
Power Supply		Polymer lithium battery: 3. 7V, 4000mAh, Power Adapter: 5VDC, 2A
Battery Working Time		Stand by >20h; Measuring time> 12
Working Temperature		-10°C~+50°C
Storage temperature		-40°C~+70°C
Relative Humidity		0-95%Non Condensing
Size		173mm×82mm×37mm
Weight		350g
Functions: CWDM OPM/OPM/VFL/RJ45 Cable Length/RJ45 Cable Sequence/RJ45 Cable Tracking(need to purchase external Cable Tracker)
