Model

S0

S1

S2

S3

S4

T1

T2

T3

T4

T5

T6

F1

M1

SM1

SM2

Type

SM

MM

SM/MM

Wavelength

1310/1550nm

1310nm/1490nm

/1550nm

1310nm/1550nm

/1625nm

1310nm/1550nm

/1650nm

1310nm/1490

/1550nm/1625nm

850nm

/1300nm

850nm/1300nm

1310nm/1550nm

Max   Dynamic

Range(dB)

32/30

35/33

38/36

42/40

45/43

32/30/30

37/35/35

32/30/30

37/35/35

32/30/30

37/35/35

37/35/35/35

26/28

26/28/35/33

26/28/37/35

Event   blind Zone

0.8m

0.5m

0.8m

0.5m

0.8m

0.5m

0.5m

1m

ATT   Blind zone

4m

3.5m

4m

3.5m

4m

3.5m

3.5m

6m

0.8m

0.5m

0.5m

1m

Test   Range

100m/500m/1.25km/2.5km/5km/10km/20km/40km/80km/125km/260km/420km

Pulse   Width

3ns/5ns/10ns/20ns   /30ns /50ns /80ns /100ns/200ns/300ns   /500ns/800ns/lus/2us/3us/5us/8us/10us/20us

Ranging   accuracy

±(0.75m+ Sample interval +0.0025 %X Test   distance)

Loss   accuracy

±0.03dB/dB

Sample   Points

≥256k

Sample   Resolution

0.015m~16m

Reflection   Accuracy

±2dB

Loss   Resolution

0.001dB

Loss   Threshold

0.01dB

File Format

SOR Standard file format

Loss    Analysis

4-point method /5-point method

Laser Safety Level

Class ll

Refresh Rate

4 Hz (Typ.）

Data Storage

Internal storage: 2GB, 200,000curves;   External storage:64GB

Connector

FC/UPC (Interchangeable SC、 ST）

Data Interface

USB-A Type-C port, RJ45 LAN 10/100Mbit/s

OPM

Wavelength range

800nm~1700nm

Connector

Universal FC/SC/ST

Test scope

-50dBm~+26dBm/-70dBm~+6dBm

Uncertainty

±5%

Calibration wavelength

850nm/980nm/1300m/1310nm/1490nm/1550nm/1625m/1650nm

LS

Laser Type

FP - LD

Wavelength

Consistent with OTDR output wavelength

output power

≥-5dBm( SM fiber)

Mode

CW/270Hz/1kHz/2kHz

Stability

CW,±0.5dB/15min(Test after 15 minutes of   preheating)

Connector

FC/UPC (Interchangeable SC、 ST）

VFL

Wavelength

650nm±20nm

output power

≥10mW

Connector

FC/UPC (Interchangeable SC、 ST）

The Optical Loss Test index refers to the   above light source and optical power meter index.

Others

Display

7 inch color LCD+ touch screen   Resolution:800×480

Power supply

Type-C adapter: Input: 100V~240V,   50/60Hz, Output: 5V/3A, 9V/2A, 12V/1.5A Lithium battery: 3. 7V, 10400mAh

working temperature

-10°C~+50°C

Storage temperature

-40°C~+70°C

relative humidity

0~95%, Non Condensing

Weight

≤1.2kg

Size

215mm×160mm×50mm

Functions of Host: OTDR/VFL/ LS/OPM/Event   Map/End Detection/Optical Loss Test/Ethernet test/ Remote test/File   management

1

Host

1

2

AC/DC power adapter

1

3

Udisk (containing analysis software/User's Manual)

1

4

Data line

1

5

OTDR SC adapter

1

6

OPM SC adapter

1

7

User's Manual

1

8

Calibration certification

1

9

Certificate/ Warranty card

1

10

Clean cotton piece

10

11

Leather knob

1

12

Special backpack for instrument

1
